High Platform flanged ball valve

2PC High Platform flanged ball valve

Name: 2PC High Platform flanged ball valve

Detailed Product Description:

CLASS 150~300 FLOATING BALL VALVE

Two-piece Body,Floating Ball,Buint-in ISO5211 direct mounting pad

Full silicasol technology

Full or Reduced bore,Blowout Proof Stem

Fire safe and Anti static

Anti-static devices for ball-stem body

Double stem sealing to comply with TA-LUFT requirements

Pre-Load 2 belleville washer to self-adjust packing

Stainless steel ball

CF8(304) CF3(304L) CF8M(316) CF3M(316L)

Standards compliance

Design and Manufacture: API 608,ASME B16.34

Face to face(end to end): ASME B16.10

Flanged connection:ASME B16.5

Fire-safe: API 607,4th 1993

Test and inspection: API 598,API 6D


Contact Now

If you have High Platform flanged ball valve any enquiry about quotation or cooperation, please feel free to email us at sale@dfcvalve.com or use the following enquiry form. WINDMILL sales representative will contact you within 24 hours. Thank you for your interest in our High Platform flanged ball valve products.
