Flanged Ball Valve

Name: WCB 2PC Flanged Ball Valve

Detailed Product Description:

CLASS 150~300 FLOATING BALL VALVE

Two-piece Body,Floating Ball,Buint-in ISO5211 direct mounting pad

Full silicasol technology

Full or Reduced bore,Blowout Proof Stem

Fire safe and Anti static

Anti-static devices for ball-stem body

Double stem sealing to comply with TA-LUFT requirements

Pre-Load 2 belleville washer to self-adjust packing

Carton Steel Material

WCB

Stainless steel

CF8(304) CF3(304L) CF8M(316) CF3M(316L)

Standards compliance

Design and Manufacture: API 608,ASME B16.34

Face to face(end to end): ASME B16.10

Flanged connection:ASME B16.5

Fire-safe: API 607,4th 1993

Test and inspection: API 598,API 6D
